H3C JD118A X120 Compatible 1000BASE-SX SFP 850nm 550m Transceiver Module

The IEEE 802.3z standard includes 1000BASE-SX for transmission over multi-mode fiber, 1000BASE-LX for transmission over single-mode fiber, 100BASE-FX is a version of Fast Ethernet over optical fiber. It uses a 1300 nm near-infrared (NIR) light wavelength transmitted via two strands of optical fiber, one for receive(RX) and the other for transmit(TX), 100BASE-SX is a version of Fast Ethernet over optical fiber. It uses two strands of multi-mode optical fiber for receive and transmit. Fiberonsale.com is produce complete range for FE and GE optical fiber transceivers.

Fiberonsale.com offers the full line of SFP Ethernet transceivers for the applications of 100-155Mb/s and 1.25Gb/s, including:

SFP-SX MM 550M
SFP-LX SM 10-20KM
SFP-EX SM 40KM
SFP-ZX SM 80KM
SFP-EZX SM 120KM
SFP-CWDM
SFP-DWDM
SFP-BIDI

Product Description:
● JD118A
● Operating Data Rate up to 1.25Gbps
● 850nm VCESL Laser Transmitter
● 550m with 50/125 μm MMF
● Single 3.3V Power Supply and TTL Logic Interface
● Hot-Pluggable SFP Footprint Duplex LC Connector Interface
● Class 1 FDA and IEC60825-1 Laser Safety Compliant
● Compliant with SFP MSA Specification
● Operating Case Temperature Standard:0℃~+70℃

Applications:
● Gigabit Ethernet
● Fiber Channel
● Other Optical Links
