IBM 4 Gb Single-Port Fibre Channel PCI-X 2.0 DDR Adapter

Specifications:
Wrap plug FRU number: 012R9314
I/O bus architecture:
PCI-X 2.0a, PCI 3.0, PCI-X Mode 2 - 266 MHz, PCI-X Mode 1 - 133 MHz, PCI - 66 MHz
Slot requirement: One available 3.3 volt PCI or PCI-X slot
FC compatibility: 1, 2, 4 Gigabit
Cables:
50/125 micron fiber (500 MHz*km bandwidth cable)
1.0625 Gbps 2 – 500 m
2.125 Gbps 2 – 300 m
4.25 Gbps 2 – 150 m
62.5/125 micron fiber (200 MHz*km bandwidth cable)
1.0625 Gbps 2 – 300 m
2.125 Gbps 2 – 150 m
4.25 Gbps 2 – 70 m

Operating system or partition requirements
AIX 5L? Version 5.2 with the 5200-08 Technology Level, or later
AIX 5L Version 5.3 with the 5300-04 Technology Level, or later
Red Hat Enterprise Linux version 4 U2, or later
SUSE Linux Enterprise Server 9 SP3, or later
IBM i V5R3M0 with PTFs, V5R3M5 with PTFs
IBM i V5R4M0, or later
